Sollas 20
The Sollas 20 is a versatile overwrapping machine that can be supplied with various feeding systems. The machine has proven itself at hundreds of satisfied customers worldwide.
Characteristics
- Entry level machine, competitively priced
- Highly reliable cam driven technology
- One level product infeed and outfeed
- Electronically adjustable machine speed
- Realistically priced change-parts
- Change parts from Sollas 17, 19 and S-series are compatible
- Trailing edge seal system
- Quick change-over facility
- Flexible size-ranges
- Easy operation and maintenance
- PLC
- Servo drive film feed
Specifications
| Detail technical specification | |
|---|---|
| Sollas 20 | |
| packaging style | overwrapping/banding |
| product size range (L x B x H) | |
| L | 45 - 300 mm |
| W | 40 - 200 mm |
| H (H125, H140) | 16 - 96 mm |
| products outside this range on request | |
| output max. | 50 / minute |
| size change time | 10 - 20 minutes |
| film width | 50 - 420 mm |
| filmroll diameter max. | 330 mm |
| packaging material | PP / coated paper (20 micron and up) |
| machine lay out | HL / HR / LL / LR |
| air consumption | 4 ndm3 / stroke |
| air pressure | 6 Bar |
| power consumption | 2,5 kW |
| machine weight (net) | 950 kg |
| machine dimension | see drawing |
| machine colour | RAL 9010 |
| options | teartape applicator, printmark registration, film slitting, castors, special colour, various infeed systems, felt on machine |
| drive | cam / servo |
| control | PLC |
